F 시리즈 리드와이어 부착된 포일 스트레인게이지
F 시리즈 스트레인 게이지 리드선이 부착된 게이지입니다.
스트레인 게이지 단말기 설치 및 리드선 납땜으로 리드 와이어 연결을위한 공사가 필요하지 않습니다. 때문에 많은 시간과 노동을 절약 할 수 있습니다.

  • 일반용
  • 유리/세라믹 재료
  • 잔류 응력 측정
  • 전단 변형률 측정
  • 토크 측정
  • 스트레스 집중 측정
  •
    series Leadwire integrated Foil strain gauge

    This gauge has a pre-attached vinyl lead wire to F series strain gauge. Works for lead wire connection such as strain gauge terminal installation and lead wire soldering are not required. It saves much time and labor.

    Applicable specimen
    Metal, Glass,
    Ceramics
    Backing
    Epoxy
    Operational temperature(°C)
    -20~+80°C
    Element
    Cu-Ni
    Temperature compensation range(°C)
    +10~+80°C
    Strain limit
    5%
    (50000×10-6strain)
    Bonding adhesive
    CN, P-2, EB-2
    Fatigue life at room temperature
    1×106
    (±1500×10-6strain)

    Single-element (G.F. 2.1 approx.)

    0.11mm2 integral vinyl leadwire Total leadwire resistance per meter : 0.32Ω

    FLA

    Type
    Gauge
    length
    (mm)
    Gauge
    width
    (mm)
    Backing
    length
    (mm)
    Backing
    width
    (mm)
    Resistance
    (Ω)
    Lead wire
    pre-attached
    Type name
    of lead wire
    preattached
    FLA-1-11
    FLA-1-17
    FLA-1-23
    1
    1.3
    5
    2.5
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FLA-2-11
    FLA-2-17
    FLA-2-23
    2
    1.5
    6.5
    3
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FLA-3-11
    FLA-3-17
    FLA-3-23
    3
    1.7
    8.8
    3.5
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FLA-5-11
    FLA-5-17
    FLA-5-23
    5
    1.5
    10
    3
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FLA-6-11
    FLA-6-17
    FLA-6-23
    6
    2.2
    12.5
    4.3
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT

    Each package contains 10 gauges.



    90° 2-element Cross (G.F. 2.1 approx.)

    0.08mm2 integral vinyl leadwire Total leadwire resistance per meter : 0.44Ω

    FCA

    Type
    Gauge
    length
    (mm)
    Gauge
    width
    (mm)
    Backing
    (mm)
    Resistance
    (Ω)
    Lead wire
    pre-attached
    Type name
    of lead wire
    preattached
    FCA-1-11
    FCA-1-17
    FCA-1-23
    1
    0.7
    ø4.5
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FCA-2-11
    FCA-2-17
    FCA-2-23
    2
    0.9
    ø7
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FCA-3-11
    FCA-3-17
    FCA-3-23
    3
    1.7
    ø11
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FCA-5-11
    FCA-5-17
    FCA-5-23
    5
    1.9
    ø12
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FCA-6-11
    FCA-6-17
    FCA-6-23
    6
    2.4
    ø14
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FCA-10-11
    FCA-10-17
    FCA-10-23
    10
    2.5
    ø17
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT

    Each package contains 10 gauges.



    45°/90°3-element Rosette (G.F. 2.1 approx.)

    0.08mm2 integral vinyl leadwire Total leadwire resistance per meter : 0.44ΩFRA

    Type
    Gauge
    length
    (mm)
    Gauge
    width
    (mm)
    Backing
    (mm)
    Resistance
    (Ω)
    Lead wire
    pre-attached
    Type name
    of lead wire
    preattached
    FRA-1-11
    FRA-1-17
    FRA-1-23
    1
    0.7
    ø4.5
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FRA-2-11
    FRA-2-17
    FRA-2-23
    2
    0.9
    ø7
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FRA-3-11
    FRA-3-17
    FRA-3-23
    3
    1.7
    ø11
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FRA-5-11
    FRA-5-17
    FRA-5-23
    5
    1.9
    ø12
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FRA-6-11
    FRA-6-17
    FRA-6-23
    6
    2.4
    ø14
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT
    FRA-10-11
    FRA-10-17
    FRA-10-23
    10
    2.5
    ø17
    120
    Paralleled 1m
    Paralleled 3m
    Paralleled 5m
    3-wire 3m
    3-wire 5m
    -1L
    -3L
    -5L
    -3LT
    -5LT

    Each package contains 10 gauges.
