Power supply	24V DC (16 - 30V DC), insulated
Outputs	passive current, range max. 3.4 ÷ 24 mA
Humidity	0-90%, non-condensing
Accuracy	± 0.1%@25˚C (for TC N: ± 0.2%@25˚C; for TC S, T, R, B: ± 0.5%@25˚C)
Communication interface	RS-485, 8N1 and 8N2, 1200 bit/s ÷ 115200 bit/s, Modbus RTU
Input signal	Pt100, Pt500, Pt1000; TC type K, S, J, T, N, R, B, E or milivoltage input: 0-60 mV, 0-75 mV, 0-100 mV, 0-150 mV
Operating temperature	0°C ÷ +50°C (standard), -20°C ÷ +50°C (option)
Storage temperature	10°C ÷ +70°C or -20°C ÷ +70°C (depending on version)
Case dimensions	101 x 22,5 x 80 mm
Protection class	IP 20
Min. range	depends on input signal
Maximum load	0...(Uz - 9,5V) / 24 mA [kOhm]
Mounting	DIN rail 35 mm
Measurement range	depends on input signal: -100°C ÷ +600°C for Pt; 100°C ÷ +1820°C (B); -100°C ÷ +1200°C (J); -100°C ÷ +1370°C (K); -100°C ÷ +1300°C (N); -50°C ÷ +1750°C (S); voltage signal 0-60 mV, 0-75 mV, 0-100 mV, 0-150 mV
Software	S-Config software for programming directly from PC You can find in section „Download” in upper menu. Option configurator Product code: Input: 1 x RTD / TC / milivoltage (1H) Output: no output (00) Output: 1 x current (15) Communication interface: RS-485 (1) Power supply: 24V DC (1) Options: no options (001) Options: operating temperature -20°C ÷ +50°C including PCB conformal coating (081)
